Wall Mounted Heat Pumps & Air Conditioners
TOSOT LOMO 16 -20°C
TOSOT LOMO 16 – WALL-MOUNTED HEAT PUMP
The TOSOT LOMO 16 wall-mounted heat pump is designed to deliver dependable heating and cooling performance with inverter technology. As part of the single-zone LOMO series, it combines efficiency, quiet operation, and flexible installation for residential applications.
The system maintains heating performance down to -30°C and supports low-ambient cooling operation. It is available in capacities ranging from 9 000 to 24 000 BTU.
Performance and Capacity
- Cooling efficiency – 16 SEER inverter system
- Heating performance – Ultra Heat operation down to -30°C
- Available capacities – 9 000, 12 000, 18 000, and 24 000 BTU
- Heating capacity retention – Up to 80% at -30°C and 100% at -20°C
Operating Range
- Heating operation – Down to -30°C
- Low ambient cooling – Down to -15°C
Indoor and Outdoor Sound Levels
- Indoor unit sound pressure level – As low as 19 dB(A) on low speed, depending on capacity
- Outdoor unit sound level – From 61 to 72 dB(A), depending on model
System Features
- Inverter-driven compressor
- Optional “I Feel” wall thermostat
- Wi-Fi ready
- LED display
- Two-stage superheat control
- Built-in drain pan heater
- Smart defrost function
Installation and Electrical
- Power supply – 208–230V / 60Hz / 1 phase
- Maximum piping length – Up to 82 ft (25 m), depending on model
- Maximum elevation difference – Up to 49 ft (15 m), depending on capacity
- Refrigerant – R410A
SEER:
16
EER:
10
HSPF:
9
Sound Level:
28
Model:
TW12HQ1C8DI/TW12HQ1C8DO, TW18HQ1C8DI/TW18HQ1C8DO, TW24HQ1C8DI/TW24HQ1C8DO, TW09HQ1C8DI/TW09HQ1C8DO
Minimum Operating Temperature:
-20
Series:
LOMO 16
Capacity:
18 000 BTU, 9 000 BTU, 12 000 BTU, 24 000 BTU
Refrigerant:
R-410A
Compressor Technology:
Inverter
Connectivity:
Wi-Fi
Rebate Programs:
LogisVert
Parts Warranty:
10
Labor Warranty:
10
Technology:
Inverter technology, Blue Fin coating, Turbo mode, Auto-restart function, Vertical auto swing
Aesthetics:
Minimalist and clean design, Space-saving wall unit, Smooth white finish, Discreet display screen
Technical details:
Efficiency up to 16 SEER, Operation down to -20 °C, Wi-Fi optional, R-410A refrigerant, 220V voltage, Piping: 1/4 – 3/8, Silent mode, Sleep mode, Variable-speed fan, Auto-swing louvers, Self-diagnosis, Indoor noise level: 28 / 43 dB(A), LED display
