ARCOAIRE DURACOMFORT -25°C
ARCOAIRE DURACOMFORT – HIGH-EFFICIENCY HEAT PUMP
The ARCOAIRE DURACOMFORT is a high-performance heat pump designed to deliver premium comfort and superior energy efficiency. Engineered with Ultra Heat capabilities, this system ensures reliable heating even when outdoor temperatures drop to -25°C, making it an ideal choice for cold climates.
With exceptional efficiency ratings of 24.7 SEER, 14 EER, and 10.5 HSPF, this ENERGY STAR® and AHRI certified unit combines powerful output with quiet operation. Powered by R-410A refrigerant and featuring Wi-Fi included, it offers a modern, connected, and eco-friendly solution for your home.
Premium Performance and Efficiency
- Ultra Heat Capability – Maintains effective heating performance down to -25°C.
- Top-Tier Efficiency – Achieves up to 24.7 SEER, 14 EER, and 10.5 HSPF for significant energy savings.
- Whisper Quiet – Indoor unit operates as quietly as 24.7 dB(A), ensuring a peaceful environment.
- Smart Connectivity – Comes with built-in Wi-Fi for convenient remote control and monitoring.
Specifications and Installation
- Compact Design – Indoor unit dimensions of 31.89 7.87 11.81 inches allow for unobtrusive installation.
- Piping – Uses standard 1/4 – 3/8 inch piping sizes.
- Outdoor Durability – Robust outdoor unit (31.5 13.11 21.81 inches) with a noise level of 56.6 dB(A).
Warranty and Peace of Mind
- Solid Protection – Backed by a 10-year warranty on the compressor and 10 years on parts.
SEER:
24.7
EER:
14
HSPF:
10.5
Sound Level:
24.7
Model:
DLFSHBH09XAK/DLCSRBH09AAK, DLFSHBH12XAK/DLCSRBH12AAK, DLFSHBH18XAK/DLCSRBH18AAK, DLFSHBH24XAK/DLCSRBH24AAK, DLFSHBH30XAK/DLCSRBH30AAK, DLFSHBH36XAK/DLCSRBH36AAK
AHRI:
206361869, 206361870, 206361871, 206361872, 207188906, 207188907
Minimum Operating Temperature:
-25
Series:
DURACOMFORT
Capacity:
18 000 BTU, 9 000 BTU, 24 000 BTU, 12 000 BTU, 36 000 BTU, 30 000 BTU
Refrigerant:
R-410A
Connectivity:
Wi-Fi
Certifications:
ENERGY STAR
Rebate Programs:
LogisVert
Parts Warranty:
10
Labor Warranty:
10
Technology:
Efficiency up to 24.7 SEER (ENERGY STAR certified), Heating operation down to -25 °C, Variable-speed INVERTER compressor with built-in Wi‑Fi control, Ultra-quiet operation 24.7 dB, 10‑10‑0 warranty
Aesthetics:
Refined, modern minimalist design, Slim, unobtrusive wall‑mounted profile, Sleek, discreet visual presence, Seamless blend into interior décor
Technical details:
Heating capability: down to -25 °C, Energy efficiency (SEER): 24.7, Refrigerant: R‑410A, Voltage: 220 V, Wi‑Fi: Included, Certifications: ENERGY STAR, AHRI, Indoor noise level: 24.7 / 39.8 dB(A), Outdoor noise level: 56.6 dB(A), Compressor/parts/labor warranty: 10 / 10 / 0 years, Piping size: 1/4 – 3/8 in, Indoor unit dimensions (W×D×H): 31.89 × 7.87 × 11.81 in, Outdoor unit dimensions (W×D×H): 31.5 × 13.11 × 21.81 in
Identifier corrections:
AHRI: 208682113 → 206361869, AHRI: 208682114 → 206361870, AHRI: 208682115 → 206361871, AHRI: 208682116 → 206361872, AHRI: 208682117 → 207188906, AHRI: 208682118 → 207188907
